ClickDeck Aluminium Modular Framing
Clickdeck’s aluminium deck framing system is a moisture-resistant, precision-engineered solution built for durability and easy installation. Its modular design streamlines construction, delivering a straight, level, and long-lasting foundation with efficient planning and pricing.
Clickdeck is a smart modular decking system made for everyone from DIY homeowners to professional builders. With just a few key components such as Corner Brackets, Hold Down Clips, and Joiners, it is simple to install and adapts easily to different site conditions. The system includes a range of Profile sizes from 28 to 200, covering all deck heights from ultra-low patios to heavy-duty commercial projects. Whether you are building at home or on a job site, Clickdeck makes the process faster, stronger, and easier.
Get A Quote
Transform your outdoor space with Perth Decking Company. Contact us today for a personalised consultation and discover how our expert team can bring your vision to life. Experience the Perth Decking Company difference—where quality meets craftsmanship, and your satisfaction is our ultimate goal.
Aluminium Frame Joist / Bearers Options
Profile Heights: 28mm to 200mm
28Profile
28 x 50mm
Typical Span – 700mm
Ultra-low profile for compact decks where height and performance matter most.
Standard Lengths
3600mm
4800mm
6000mm
55Profile
55 x 55mm
Typical Span – 1200mm
The go-to profile for most decks. Versatile, reliable, and suited for a wide range of everyday decking needs.
Standard Lengths
2400mm
3600mm
4800mm
6000mm
110Profile
110 x 50mm
Typical Span – 1900mm
Great for elevated decks and wider spans, this profile delivers dependable strength in more open designs.
Standard Lengths
3600mm
4800mm
6000mm
150Profile
150 x 50mm
Typical Span – 2700mm
Perfect for heavy-duty builds, offering strong structural support and added stability for demanding deck applications.
Standard Lengths
6000mm
200Profile
200 x 50mm
Typical Span – 3400mm
Built for maximum span and strength, ideal for large commercial and industrial projects that need serious load support.
Standard Lengths
6000mm
Bracket / Clip / Joiner
Corner Bracket
Provides strong, precise 90-degree connections at frame intersections. Essential for building a solid and stable deck structure. Can be bent for angled connections.
Hold Down Clip
Secures the frame to the ground or surface, keeping your deck firmly in place and resistant to movement or uplift.
Joiner
Connects two profiles together for seamless, continuous runs. Ideal for extending deck lengths while maintaining strength.
Deck Support
Pedestal Pro
Smart, modular support for decking and pavers. Strong, stable, and adjustable, perfect for both residential and commercial use.
55Profile Post KIt
Lightweight aluminium post using 55Profile with screw-on brackets. Ideal for residential decks.
100Profile Post KIt
Heavy-duty 100 x 100mm post with top and bottom brackets. Suitable for heights up to 2000mm for commercial use.
